7Kw 11kw range - belt drive



DA Series - Screw Air Compressors

7 kW to 11 kW  (8.5-127.5 cfm)

Atlas Copco G Series screw compressor available in  7.5 kW, 11 kW,  is the perfect choice for your business. It brings the power and durability of an industrial screw compressor to any type of small or medium sized industry.


7-11kW Screw Compressors


The DA Series screw compressor is built to last and perform with robust element, and a motor delivering efficient performance and come with state-of-the-art monitoring and has the option for remote monitoring. The 7KW to 11KW compressors form Atlas Copco are built to last with rugged screw compressor technology, and has a 100% duty cycle. The DA Series screw compressors robust components mean it can withstand temperature of up to 46°C ambient temperature.


Available in different pressure variances

The 2kW to 5kW compressors available in 10 bar the 7.5 kW up to 22kW is available in pressure variances from 7.5 bar to 13 bar. Available in Floor mount, Tank mount and full feature variances the G Series screw compressor has the feature and specs to suit any business’s needs.


Get your compressor today

The G Series screw compressor is your choice for performance, technology and durability without breaking the bank. Call us today on 1800 822 220 or email jason@CPScompressors.com.au for a free quote.


When you get your next screw compressor make sure it is from the world leader in compressed air technology and ensure it is an Atlas Copco G Series from Complete Pneumatic Solutions.

Remember we can assist with the correct choice. We also install and look after service.


Available with Upgraded Controller, SMARKLINK, EWD (Electronic Water Drain) & Extended warranty (subject to usual terms)




Atlas Copco’s G compressors bring you outstanding sustainability, reliability and performance,

while minimizing the total cost of ownership. This range provides you with the compressed air

solution that perfectly matches your requirements with clear value propositions. Built to perform

even in the harshest environments, these compressors keep your production running efficiently.

Learn More

Click here for Brochure


G 2-5/G 7-11/G 15-22/G 30-45/G 55-75 -90 (2 -90kw)

A ROBUST MULTIPLE OFFER Integrated quality air solutions

• The integrated dryer avoids condensation and corrosion in the network. Optional filters for air quality up to class 1 level (<0.01 ppm).

• Standard included water-separator.

• Additional energy savings with the dryer’s no-loss mechanic drain.

Easy installation

• A true plug-and-play solution, ideal machine

for installation companies and OEMs.

• Easy transportation by forklift.

• Remarkably compact footprint.


Robust element & motor

• The G’s compression element, the most used in its size.

• 2-3% higher efficiency with V-belt compared to

other belt-driven systems on the G 2-22.

• Gear-driven drive train on G 30-75 for unequaled

reliability and limited maintenance.


Advanced monitoring

• State-of-the-art monitoring using a simple

Ethernet connection.

• Service and warning indications, error detection

and compressor shut-down.

• Optional Elektronikon® graphic controller for

further enhanced remote monitoring features

and service time indications.


High tech oil vessel

• Protection from oil contamination: extremely low oil carry-over thanks to the vertical design of the oil vessel.

• Extremely low losses of compressed air during load/unload cycle thanks to minimse oil vessel size.



DA Range available IN OUR STORE

Rotary Screw compressor flow P&ID

Downloads

G2-75 2kw to 75kw Australia Atlas Copco Air Compressors 2019 (pdf)Download
